Portable CMM RA325 Articulated Arm Coordinate Measuring Machine 3D Measuring Arm
Product Description
RUYA portable CMM is an economical and practical, cost-effective highlight measuring equipment, the main applications are:
- Aerospace, automotive, parts manufacturing, engineering machinery and precision measurement of the assembly process
- Dies, jigs, submit verification measurement
- New product development, first article inspection, periodic testing parts
- Industrial products, clay model, sample, reverse engineering works of art
After you use the device to fully expand the measurement range, at any time convenient measurement; second measure is to save time, improve measurement efficiency; reduce duplication of equipment investment, improve equipment utilization, production cost savings
Basic functions
Geometric feature detection
1. Measure the geometric features on the workpiece. And through projection and intersection, existing geometric features are fitted to generate new features.
2. Quickly analyze spatial dimensions such as distances and angles between geometric features.
3. The coordinate system can be customized through points, lines, and surfaces, and linear dimensions can be marked.
GD&T geometric tolerance detection
The measurement software provides GD&T tools to evaluate the form and position tolerances of geometric features. For example, verticality, parallelism, flatness, cylindricity, coaxiality, inclination, position, etc.
Comparison between 3D model and actual object
The software is compatible with multiple 3D data formats and provides multiple coordinate alignment methods. It can automatically compare measured geometric features and surface point data with theoretical values on the three-dimensional model, and provide error analysis graphic reports.
Test report
Test reports in PDF, Excel, and mht formats can be quickly output.
The inspection report customization function is powerful, and the output report is convenient and fast, with pictures and texts.
Application fields: used for auto parts, motorcycle frames, pipe fitting measurement, robotic arm measurement, sheet metal manufacturing, material rack factory, teaching demonstration, etc.
Product parameters
| RA3 Series Specification |
| Model | Spatial measurement range/m | Space-length indication error/mm | Uniaxial coordinate measurement consistency /mm |
| RA315 | 1.5m | 0.06mm | 0.03mm |
| RA320 | 2.0m | 0.08mm | 0.04mm |
| RA325 | 2.5m | 0.11mm | 0.06mm |
| RA330 | 3.0m | 0.14mm | 0.08mm |
| RA335 | 3.5m | 0.18mm | 0.12mm |
Optional Accessories:
|
|
